Norminal Voltage: 12.8V
Chemistry material: Li(CoNiMn)O2
Norminal Capacity: 100Ah
Power: 350w
Charge Cut-off Voltage: 14.6V
Discharge Cut-off Voltage: 10V
Standar Charge Current : 20A
Dimention: 225*165*160mm
Fast Charge Current: 50A
Weight: around 13kg
Continuous Discharge Current: ≤80A

Main Spec:
Norminal Voltage: 12.8V
Chemistry material: Li(CoNiMn)O2
Norminal Capacity: 100Ah
Power: 350w
Charge Cut-off Voltage: 14.6V
Discharge Cut-off Voltage: 10V
Standar Charge Current: 20A
Dimention: 225*165*160mm
Fast Charge Current: 50A
Weight: around 13kg
Continuous Discharge Current: ≤80A
Operating Temperature: -20–60℃
Pulse Discharge Current: 100A
Storage Temperature: 0-45℃
Cycle Life: ≥2000times
Warranty: 1.5 years

Supports Bluetooth BMS App:
1. The protection board supports any battery pack (lithium titanate, iron lithium, ternary, etc.) within 24 strings (the power supply voltage must be greater than 24v)
2. Support Bluetooth connection setting parameters, view parameters
3. Supports screen display of battery pack status, parameters, and voltage of each cell
4. The over-discharge protection voltage can be set arbitrarily within this range.
Ant protection board bluetooth app
5. Using a controlled equalization method, the equalization can be started after the detected pressure difference is greater than the set value during charging.
6. Battery pack monomer voltage detection, voltage detection range 1-5v (less than 1v and higher than 5v can not be detected), high precision, comprehensive error less than 5mv, suitable for all battery packs with voltage within this range, overshoot protect,
7. Current measurement (support current measurement within 200a)
8. Coulomb counter function, based on the integration of current to time, accurately calculate the remaining capacity of the battery, charge into the power, etc.
9. Based on the motor Hall pulse detection speed, and can calculate the remaining cruising range
10. Independent 6-channel temperature measurement, temperature over-temperature protection value can be set
In anywhere you can go to check from your celluar phone to check the SOC and battery status from the App.
